WATER LEVEL SENSOR

Original price was: ₹399.Current price is: ₹299.

17 products sold in last 14 hours
Selling fast! Over 19 people have in their cart

The water level sensor is a critical component of the water level indicator project. It is designed to detect water levels and provide an output based on the resistance of the water present in the tank. The sensor consists of a series of parallel exposed conductors, acting as a variable resistor. When submerged in water, the sensor’s resistance changes, allowing it to indicate different water levels.

28 people are viewing this right now
  • Check Mark Estimated Delivery : Up to 4 business days
  • Check Mark Free Shipping & Returns : On all orders over $200
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout

General Description:

The water level sensor is a critical component of the water level indicator project. It is designed to detect water levels and provide an output based on the resistance of the water present in the tank. The sensor consists of a series of parallel exposed conductors, acting as a variable resistor. When submerged in water, the sensor’s resistance changes, allowing it to indicate different water levels.

Working Principle:

The sensor operates based on the principle of variable resistance. As more water is present in the tank and the sensor is submerged, the conductivity increases, leading to lower resistance. Conversely, less water results in higher resistance. The sensor’s analog output is proportional to the resistance, allowing you to determine the water level.

Specifications:

1. The operating voltage range is 3 to 5 volts DC.

2. Maximum operating current is 20 mA.

3. The detecting range of the sensor is 40 x 16 mm.

4. The sensor type is Analog.

5. Operating temperature ranges from -10 to 30 °C.

6. Humidity range tolerated is 10% to 90% non-condensing.

7. Length measures 60 mm, width 20 mm, and height 1.5 mm.

WATER LEVEL SENSOR

Requirements



S. No. Component Name Values
1 RCWL-9183 (voltage regulator – 1.8V)
2 MAX30100 (IR trans receiver sensor)
3 Resistors 472R
4 Capacitors 106, 104, 105(n)
5 Male connectors 7



Pin configuration:



S. No. Pins Pin Description
1 VIN Input voltage (1.8V to 3.3V)
2 SCL IIC-SCL
3 SDA IIC-SDA
4 INT MAX30100INT
5 IRD IR LED Cathode and LED Driver Connection Point. Leave floating in circuit.
6 RD Red LED Cathode and LED Driver Connection Point. Leave floating in circuit.

Applications:
1. Can be used in water tanks to control water levels.

2. Water leakage detection.

3. Automatically turn ON/OFF pumps.

4. Can be used in factories, commercial complexes, apartments, home.

5. Fuel tank level gauging.

6. Oil tank level control.

7. Rain Monitoring System.
